better products

Filter Press Cloth

Filter Cloth is a media, where genuine filtration happens. Filter Cloths mounts on the deplete surface of the Filter Plates. At the point when slurry nourishes inside the Filter Plate chamber, the slurry gets filtered through the Filter Cloth.

NMP is the worldwide expert on filter cloths, the key fixing to enhance your filter press operations. We take incredible care to survey every client’s procedure and application to outline a filter cloth that is customized to every client’s demanding necessities. From natural to synthetics and felted materials, NMP offers a broad stock of solid, elite filter cloth materials to meet your filtration needs.

We realize that guaranteeing a fast and responsive turnaround is principal agreeable to you. We work with trusted providers in nearness to our assembling areas to guarantee that we have close by the cloth materials required for your particular application.

Features

  • NMP is your first and last source for cloths for your Filter Press.
  • Proper material selection impacts performance. NMP has one of the widest ranges of materials available. We will help you choose the ideal material for your application.
  • The weave of your filter cloth will also depend on your specific application. For example if your application is mining for gold we have specific filter cloths designed to withstand extreme pressures, that capture particulates as small as .05 microns. If your application is metal finishing, or other heavy industrial applications that require cleaning and processing industrial wastewater we have filter cloths that will apply to your specific need. Learn How to Choose the Right Filter Cloth for Your Dewatering Process.
  • Our state-of-the-art laboratory staff can assist in the specification of your filter cloth. Because there are different types of cloth weaves and materials, we want to ensure the correct cloth is specified for your application. Your filter cloth specification will depend on the size of your press and the dewatering application it's being used in. For example, a battery recycling plant will utilize a different sized filter cloth and filter press than a municipal power plant whose application is separating sulfur dioxide from their slurry.
Products Filter Cloth
Products Filter Cloth
Products Filter Cloth
Products Filter Cloth
Products Filter Cloth
Technical Data of the Filter Cloths
Format Standard Sizes (in mm): 400, 470, 500, 630, 800, 915, 1000, 1067, 1200, 1300, 1450, 1470, 1500, 1500 x 2000 and 2000 x 2000 mm. These formats are available in open and closed versions. Larger and differently sized formats on request.
Sludge Inlet Standard inlets: central inlet, decentralized inlet, corner inlet
Pressure Depending on the version, standard products are suitable for a maximum filtration pressure of 8 bar or 16 bar.
Temperature The maximum permissible filtration temperature depends, among other things, on the filtration pressure, the chemical composition of the slurry to be filtered, the cycle time and the choice of material.
Materials Filter Cloths can be made of the following materials for specific applications:
  • Polypropylene (PP) (heat-stabilized and if necessary calendared)
  • Polyamide (Nylon-6 &6.6), (heat-stabilized)
  • Polyester (PET), (Heat set calendared)
  • PBT (Heat set calendared)
  • Cotton, Poly Cotton
  • Other materials on request
Weaves
  • SPUN yarn
  • Multifilament yarn
  • Monofilament yarn
  • Yarn blends (Multi x Spun& Mono x Multi)
  • Plain weave
  • Broken twill weave
  • Twill weave
  • Satin weave
Versions Filter cloths can be made for Non-Gasketed (NG) or Caulked, Gasketed Recessed (CGR) chamber plates.
